The AW8-MAX, however, is a well-rounded board in most respects, including features. ABIT's Fatality motherboards concentrated on performance and overclocking before all else. Moving on around and past the two PCI slots and the backwards-facing slot that ABIT uses to add an audio riser card, we see two x1 PCI Express slots just below the longer x16 slot that's reserved for graphics cards. Texas Instruments continues to be ABIT's high-end provider of choice, with both the company's TSB82AA2 and TSB81BA3 ASICs working in tandem to deliver two 1394b ports and a single 1394a port. Intel's ICH7R doesn't provide support for FireWire, so each manufacturer here has to integrate ASICs themselves. It's also nice to see colour-coded motherboard-to-case pins, as well. To the right is the customary big-headed clear CMOS jumper, and below that is the useful debug LED display that stops at a number or code, during the POST sequence, if something goes awry. It provides a wealth of voltage/speed manipulation options. The large ASIC just below the four SATA ports is ABIT's µGuru monitoring/tweaking chip. ABIT carries over a few of its better features from other deluxe models.
GIGABYTE INTEL 955X 945 SERIES MOTHERBOARD DRIVER SERIAL
Of course, being an i955X board, the AW8-MAX also supports the few 266MHz FSB Extreme Edition processors, too.Ĭommon to this trio of motherboards is Intel's ICH7R southbridge, replete with four on-chip Serial ATA 2 ports, HD audio and copious amounts of USB 2.0 connectivity. ABIT plays it safe by affording official support to DDR 2 667MHz RAM with LGA775 CPUs running at 200MHz. The i955X chipset runs with DDR 2 memory at varying frequencies depending upon manufacturer. ABIT packs in both the 24-pin and 4-pin power connectors within easy reach of the system PSU. The OTES system's heatpipe has been designed not to interfere with the mounting of CPU coolers, and, thankfully, the socket area is easily accessible, making installation a cinch. ABIT also adds what it terms "OC strips" on the back of the PCB, with an eye to increasing heat dissipation. It should, in theory, be better than the average oversized, fanless heatsink found on most models.
The lengthy heatpipe hooks up to a radiator-like section which is located on the top-right of the board.
This makes sense as a number of mid-range video cards are now being silently cooled using the same approach. ABIT's Silent OTES system reaches a happy medium between enthusiast overclocking and quiteness by using a heatpipe-cooled North Bridge. Motherboard manufacturers usually have to decide between mounting a noisy 40mm fan, albeit one that can sometimes controlled via BIOS software, or use a large heatsink. It's hard to ignore the AW8-MAX's North Bridge cooling, so let's skip right to it. The hot-running MOSFETs around the CPU area are all cooled by a set of four heatsinks, although unlike the Fatal1ty series of boards, ABIT doesn't implement any fan-based cooling. ABIT has gone to some lengths to prioritise board cooling.
GIGABYTE INTEL 955X 945 SERIES MOTHERBOARD DRIVER FREE
ABIT AW8-MAXĪBIT's attempt to fill the board with high-end features doesn't leave much free PCB space. Read on to find out if any or all are right for you. We've had the chance to evaluate three i955X-based retail motherboards from ABIT, Gigabyte and Intel, respectively. Intel will tell you to go for a retail board based on its i955X chipset, which is the successor to the decent-performing i925XE and offers dual-core CPU support but, as of now, no official dual-card 3D graphics tech, be it Nvidia's SLi or ATI's delayed CrossFire. Let's assume that you've opted to go down the Intel LGA775 route and want the best possible motherboard available. In short, your motherboard has to be good or your system won't be. Having to replace a motherboard usually necessitates a long-winded process of reinstalling an OS, programs and data. Making a bad choice can lead to problems that aren't apparent for, say, CPUs and processors. The choice of motherboard defines, in part, just how future-proof a system will be. Review Which motherboard to buy? Determining the answer to this question is, arguably, the most important of all hardware choices.
